ZETA Smart Connect Multiloop 6 expansion port panel

FEATURES

Modularconstructionallowsapaneltobespecified using just the required modules. Up to 4 loop card modules. 4.3” colour touch screen display. Capacity for up to 6 intelligent modules. Full system redundancy. Connection to TCP/IP Module. Extensive Day/Night mode programming. Fullcauseandeffectprogrammingviafrontpanelor theSmartconfiguratorPCsoftware. 8032 event log entries. using multiple zone monitor modules, the panel can be configuredintoafullyfunctioningconventionalpanel. 250 fyreye MKII devices per loop. 254 addresssable programmable zones. Up to 64 panel peer-to-peer network. Positive Alarm Sequence. AlarmVerification Day/night (Building occupied/unoccupied) programming. Alarm circuit special application 24V mode. 400W Power Supply. Description The SMART6 Multi-loop is a powerful and sophisticated Analogue Addressable Fire Alarm Control Panel that offersavarietyofmodularcomponentswhichallowitto meet a wide variety of applications. The graphical touch screen provides a clear, uncluttered and intuitive interface which results in the end user requiring minimal training. The control panel has the capability to support complex causeandeffectprogrammingandawiderangeof user controllable functions that make the panel suitable for a vast range of projects from multi-site commercial developments through to industrial applications. It can operate as part of a networked system of up to 64 panel’s peer-to-peer, or a standalone panel. It has powerfulprogrammingoptionsthatallowconfigurable controloverwhethermessagesfromspecificpanels are transmitted around the network or remain local. Eachsystemcomponenthasbeenspecifically designed to operate as part of a Smart Multi-loop EN54 listed system providing assurance that the detectors, interfaces, sounders, and panel are all fully compatible with each other and that the full range of system functionality is supported by all devices. 2831-CPR-F45140832-UKCA-CPR-F1331 C330w/01 1
